Decision Tree Classification

# Importing the dataset

dataset = read.csv('Social_Network_Ads.csv')

dataset = dataset[3:5]

# Encoding the target feature as factor

dataset$Purchased = factor(dataset$Purchased, levels = c(0, 1))

# Splitting the dataset into the Training set and Test set

# install.packages('caTools')

library(caTools)

set.seed(123)

split = sample.split(dataset$Purchased, SplitRatio = 0.75)

training_set = subset(dataset, split == TRUE)

test_set = subset(dataset, split == FALSE)

# Feature Scaling

training_set[-3] = scale(training_set[-3])

test_set[-3] = scale(test_set[-3])

# Fitting Decision Tree Classification to the Training set

# install.packages('rpart')

library(rpart)

classifier = rpart(formula = Purchased ~ .,

                   data = training_set)

# Predicting the Test set results

y_pred = predict(classifier, newdata = test_set[-3], type = 'class')

# Making the Confusion Matrix

cm = table(test_set[, 3], y_pred)

# Visualising the Training set results

library(ElemStatLearn)

set = training_set

X1 = seq(min(set[, 1]) - 1, max(set[, 1]) + 1, by = 0.01)

X2 = seq(min(set[, 2]) - 1, max(set[, 2]) + 1, by = 0.01)

grid_set = expand.grid(X1, X2)

colnames(grid_set) = c('Age', 'EstimatedSalary')

y_grid = predict(classifier, newdata = grid_set, type = 'class')

plot(set[, -3],

     main = 'Decision Tree Classification (Training set)',

     xlab = 'Age', ylab = 'Estimated Salary',

     xlim = range(X1), ylim = range(X2))

contour(X1, X2, matrix(as.numeric(y_grid), length(X1), length(X2)), add = TRUE)

points(grid_set, pch = '.', col = ifelse(y_grid == 1, 'springgreen3', 'tomato'))

points(set, pch = 21, bg = ifelse(set[, 3] == 1, 'green4', 'red3'))

# Visualising the Test set results

library(ElemStatLearn)

set = test_set

X1 = seq(min(set[, 1]) - 1, max(set[, 1]) + 1, by = 0.01)

X2 = seq(min(set[, 2]) - 1, max(set[, 2]) + 1, by = 0.01)

grid_set = expand.grid(X1, X2)

colnames(grid_set) = c('Age', 'EstimatedSalary')

y_grid = predict(classifier, newdata = grid_set, type = 'class')

plot(set[, -3], main = 'Decision Tree Classification (Test set)',

     xlab = 'Age', ylab = 'Estimated Salary',

     xlim = range(X1), ylim = range(X2))

contour(X1, X2, matrix(as.numeric(y_grid), length(X1), length(X2)), add = TRUE)

points(grid_set, pch = '.', col = ifelse(y_grid == 1, 'springgreen3', 'tomato'))

points(set, pch = 21, bg = ifelse(set[, 3] == 1, 'green4', 'red3'))

# Plotting the tree

plot(classifier)

text(classifier)
